R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-33
Table 4-9MKR (2 of 2)
(*1) n = 11 (fixed) fn = 10 different frequencies + ∆MKR, <DLM> = Delimiter
(*2) n = 11 (fixed) ln = 10 different levels + ∆MKR, <DLM> = Delimiter
(*3) n = Number of Peaks fn, ln = Frequency (time), level <DLM> = Delimiter
Function Listener Code
Talker Request
Code Output Format
Peak ∆Y div DY * DY? ∆Y(real value)
Peak range
Normal
Upper side
Lower side
PSN
PSU
PSL
PKRNG? 0:All
1:Upper
2:Lower
Malti Marker ON
OFF
MLT ON
MLT OFF
MLT? 0:OFF
1:ON
Moving the active marker MK *
MKN *
MN *
–––
–––
–––
–––
–––
–––
Malti Marker No1 ON
OFF
MLN1 *
MLF1
–––
–––
–––
–––
Malti Marker No2 ON
OFF
MLN2 *
MLF2
–––
–––
–––
–––
Malti Marker No3 ON
OFF
MLN3 *
MLF3
–––
–––
–––
–––
Malti Marker No4 ON
OFF
MLN4 *
MLF4
–––
–––
–––
–––
Malti Marker No5 ON
OFF
MLN5 *
MLF5
–––
–––
–––
–––
Malti Marker No6 ON
OFF
MLN6 *
MLF6
–––
–––
–––
–––
Malti Marker No7 ON
OFF
MLN7 *
MLF7
–––
–––
–––
–––
Malti Marker No8 ON
OFF
MLN8 *
MLF8
–––
–––
–––
–––
Malti Marker No9 ON
OFF
MLN9 *
MLF9
–––
–––
–––
–––
Malti Marker No10 ON
OFF
MLN10 *
MLF10
–––
–––
10 frequencies + ∆MKR
10 levels + ∆MKR
Malti Marker Frequency
Malti Marker Level
–––
–––
MLSF?
MLSL?
n<DLM> f1<DLM>... (*1)
n<DLM> l1<DLM>... (*2)
Peak List Frequency
Level
OFF
PLS FREQ
PLS LEVEL
PLS OFF
–––
–––
–––
–––
–––
–––
Peak list query ––– PKLST? n<DLM> f1,l1<DLM>... (*3)
