R3132 Series Spectrum Analyzer Operation Manual
4.2.8 Status Byte
4-18
(2) Event Enable Register
Each event register has an enable register to determine which bit is available. The enable register
sets the corresponding bit in decimal value.
• Set of Service Request Enable Register: *SRE
• Set of Standard Even Status Enable Register: *ESE
• Set of Operation Status Enable Register: OPR
Example: Only the Measuring bit in the operation status register is available.
The OPR bit of the status byte register is set to 1 when the Measuring bit of the op-
eration status register is set to one.
PRINT @8;“OPR16” (An example of the program in N88BASIC)
OUTPUT 708;“*OPR16” (An example of the program for the HP200 and
300 series)
Example: The OPR (the summary of Operation Status Register) bit and ESB (the summary of
Event Status Register) bit of the status byte register are available.
The MSS bit of the status byte register is set to 1 when the OPR bit or the ESB bit
is set to one.
PRINT @8;“SRE160” (An example of the program in N88BASIC)
OUTPUT 708;“*SRE160” (An example of the program for the HP200 and
300 series)
(3) Standard Operation Status Register
Bit assignments for the event register (which represents the standard operation status) is listed
below:
Bit Functional definition Description
15 to 10 This is always 0
9 Printing This is set to 1 at the end of printing
8 Averaging This is set to 1 when averaging is completed
7 to 5 This is always 0
4 Measuring This is set to 1 at the end of sequence measurement
3 Sweeping This is set to 1 when sweeping is completed
2 to 1 This is always 0
0 Calibrating This is set to 1 when calibration data acquisition finishes
To Next Page
