R3132 Series Spectrum Analyzer Operation Manual
4.2.9 GPIB Command Codes
4-41
Table 4-15 EMC
(*1) QP BW 200 Hz is available only when the Narrow Band RBW option is installed.
(*2) Available when EMC Trace Detection is set to Peak.
(*3) The asterisks "*,*" represent a frequency and its level. Specify them in order.
Function Listener Code
Talker Request
Code Output Format
EMC Trace Detection
:QP
:PEAK
:Normal
EMCDET QP
EMCDET PEAK
EMCDET NRM
EMCDET? 0:Normal
1:QP
3:PEAK
QP BW 200Hz
QP BW 9kHz
QP BW 120kHz
QP BW 1MHz
QP BW auto
QP0 (*1)
QP1
QP2
QP3 (*2)
QPAUTO
QA
QPAUTO?
QA?
0:AUTO
1:200Hz
2:9kHz
3:120kHz
4:1MHz
Antenna Selection
Dipole
(TP1722)
Log-periodic
(UHALP9107)
Biconical
(BBA9106)
Bilog
(EMC03142)
User correction
Antenna OFF
ANT0
AN0
ANT1
AN1
ANT2
AN2
ANT3
AN3
ANT4
AN4
ANT OFF
AF
ANT? 0:OFF
1:Dipole
2:Log-periodic
3:Biconical
4:Bilog
5:User correction
User correction ON
OFF
CR ON
CR OFF
–––
–––
–––
–––
Table input CRIN *,* (*3) ––– –––
Table erase CRDEL ––– –––
Antenna mode
Level mode
CR ANT
CR LVL
CR? 0:Antenna
1:level
