R3132 Series Spectrum Analyzer Operation Manual
5.2.2 Calibrator Amplitude Accuracy
5-9
5.2.2 Calibrator Amplitude Accuracy
The amplitude accuracy of the analyzer’s CAL OUT signal is checked for -20 dBm ± 0.3 dB.
Specification:
-20 dBm ± 0.3 dB
Instruments Required:
Procedures:
Setup
1. On the power meter, perform the zeroing and calibration with power sensor.
2. On the power meter, set the unit into dBm mode, after calibration has done.
3. On the power meter, set the correction frequency to 30 MHz.
4. Press SHIFT, CONFIG(PRESET).
Measuring the CAL OUT level
5. Connect the power sensor as shown Figure 5-2.
Instruments Qty. Recommended Model
Power Meter 1 NRVS
Power Sensor 1 NRV-Z51
Power Sensor 75 Ω 1* NRV-Z3
Adapter BNC(m)-N(f) 1
Adapter BNC(m)-N(f) 75 Ω 1*
* R3132N Only
