5.2.13 Image, Multiple and Out-of-Band Responses
5-47
5.2.13 Image, Multiple and Out-of-Band Responses
This performance verification applies for R3162/72/82.
Image, multiple, and out-of-band responses are tested in all frequency bands. A signal is applied to the sig-
nal analyzer’s INPUT connector, then a reference amplitude measurement is made.
The signal source is then tuned to a frequency which causes either an image, multiple, or out-of-band re-
sponse.
The amplitude displayed on the spectrum analyzer is measured and recorded.
Specification:
Apply for R3162
≤ -70 dBc/Hz Frequency Range up to 8 GHz
Apply for R3172
≤ -70 dBc/Hz Frequency Range 10 MHz to 18 GHz
≤ -60 dBc/Hz Frequency Range 18 GHz to 23 GHz
≤ -50 dBc/Hz Frequency Range 23 GHz to 26.5 GHz
Apply for R3182
≤ -70 dBc/Hz Frequency Range 10 MHz to 18 GHz
≤ -65 dBc/Hz Frequency Range 18 GHz to 26.5 GHz
≤ -60 dBc/Hz Frequency Range 26.5 GHz to 34 GHz
≤ -50 dBc/Hz Frequency Range 34 GHz to 40 GHz
Instruments Required:
Instruments Qty. Recommended Model
Signal Generator 1 SMP04
Power Meter 1 NRVS
Power Sensor 1 NRV-Z55
Power Splitter 1 K241C
RF Cable BNC(m)-BNC(m) 1 MI-09
RF Cable SMA(m)-SMA(m) 3 A01002
RF Cable K(m)-K(m) 1
*2
Minimum Loss Pad 1
*1
HP11852B
Adapter N(m)-SMA(f) 1
Adapter K(f)-K(f) 1
*2
*1 R3132N Only
*2 R3182 Only
