R3132 Series Spectrum Analyzer Operation Manual
5.3.1 Absolute Output Level Accuracy
5-91
CAUTION: Use only 75
Ω
ΩΩ
Ω
cables, connectors, or adapters on R3132N, or damage
to the input connector will occur.
Measuring the Tracking Generator Output Level
4. On the R3132 series, after preset, set controls as follows:
Center Frequency: 30 MHz
Span Zero: Span
TG Output Level: -10 dBm
TG: ON
5. On the power meter, set correction frequency to 30 MHz.
6. Record the measurement value of the power meter on the performance verifica-
tion record sheet.
