5.3.3 Output Level Switching Accuracy
5-95
5.3.3 Output Level Switching Accuracy
Measure the switching accuracy of TG output attenuator, after CAL ALL performed.
Measure level of several frequency against output level -10.0 dBm as reference.
The measurement of deviation from -10 dBm point using normalize function.
When change TG output level, reference level setting also change for trace data to stay center of vertical
on the screen.
Specification:
±1.0 dB Frequency Range 100 kHz to 1 GHz, TG level ≥-30 dBm
±2.0 dB Frequency Range 100 kHz to 2.6 GHz
±3.0 dB Frequency Range 100 kHz to 3 GHz
Instruments Required:
Procedures:
Calibration
1. On the R3132 series, after preset, press as follows to perform auto calibration.
SHIFT, 7(CAL) and Cal All.
Initialization
2. Press SHIFT and CONFIG(PRESET).
Setting the measurement conditions
3. Connect the SMA cable from TG OUT connector to the INPUT connector as
shown Figure 5-24.
Instruments Qty. Recommended Model
RF Cable BNC(m)-BNC(m) 3 MI-09
RF Cable BNC(m)-BNC(m) 75 Ω 1* DCB-FFA701X01
Adapter N(m)-BNC(f) 1
Adapter N(m)-BNC(f) 75 Ω 1*
* R3132N Only
