R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-122
• For the R3172 only
• For the R3182 only
(4) Resolution Bandwidth Switching Uncertainty
Test Data
Frequency Band
Specification Result
Preamplifier Min. (dBm)
Measured Value
(dBm)
Max.
(dBm)
Pass/Fail
OFF 3.2 GHz to 7.1 GHz N/A -112.0
7 GHz to 14.7 GHz N/A -111.0
14.5 GHz to 22 GHz N/A -107.0
22 GHz to 26.5 GHz N/A -104.0
Test Data
Frequency Band
Specification Result
Preamplifier Min. (dBm)
Measured Value
(dBm)
Max.
(dBm)
Pass/Fail
OFF 3.2 GHz to 7.1 GHz N/A -114.0
7 GHz to 14.7 GHz N/A -112.0
14.5 GHz to 27 GHz N/A -110.0
26.5 GHz to 30 GHz N/A -107.0
29.5 GHz to 40 GHz N/A -106.0
Test Data Specification Result
RBW (Hz) Span Setting (Hz) Min. (dB)
Measured Value
(dBm)
Max. (dB) Pass/Fail
300 k 1 M Ref. 0 (Ref.) Ref.
3 M 5 M -0.5 +0.5
1 M 2 M -0.5 +0.5
100 k 200 k -0.5 +0.5
30 k 50 k -0.5 +0.5
10 k 20 k -0.5 +0.5
3 k 5 k -0.5 +0.5
1 k 2 k -0.5 +0.5
