ADVANTEST R3162 - Page 442

R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-131
(12) Image, Multiple, and Out of Band Response
Center
Frequency
(GHz)
Frequency of
Signal
Generator
(GHz)
Specification Result
Min. (dB)
Measured
Value (dB)
Max. (dB) Pass/Fail
2 1.9572 N/A -70
2 1.1572 N/A -70
2 10.5228 N/A -70
2 8.2614 N/A -70
Apply for R3162
5.5 6.3428 N/A -70
8 7.1572 N/A -70
8 3.7893 N/A -70
Apply for R3172
5.5 6.3428 N/A -70
5.5 11.4214 N/A -70
5.5 17.3428 N/A -70
5.5 23.2642 N/A -50
12 12.8428 N/A -70
12 5.7893 N/A -70
12 18.2107 N/A -60
12 24.4214 N/A -50
21 21.8428 N/A -60
21 6.71907 N/A -70
21 13.8595 N/A -70
24.4 25.2428 N/A -50
24.4 5.78395 N/A -70
24.4 11.9893 N/A -70
24.4 18.19465 N/A -60
Apply for R3182
5.5 6.3428 N/A -70
5.5 11.4214 N/A -70
5.5 17.3428 N/A -70
5.5 23.2642 N/A -65
12 12.8428 N/A -70
12 5.7893 N/A -70
12 18.2107 N/A -65
12 24.4214 N/A -65
21 21.8428 N/A -65
