R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-135
(15) Frequency Response
• Frequency Range 9 kHz to 3.3 GHz
*1 On the R3172/82, specification is ±0.6 dB (100 kHz - 3.0 GHz) or ±1.5 dB (9 kHz - 3.3 GHz).
Preamplifier
Test Data
(MHz)
Specification
*1
Result
Min. (dB)
Measured
Value (dB)
Max. (dB) Pass/Fail
OFF 100 -0.5 +0.5
200 -0.5 +0.5
300 -0.5 +0.5
400 -0.5 +0.5
500 -0.5 +0.5
600 -0.5 +0.5
700 -0.5 +0.5
800 -0.5 +0.5
900 -0.5 +0.5
1000 -0.5 +0.5
1100 -0.5 +0.5
1200 -0.5 +0.5
1300 -0.5 +0.5
1400 -0.5 +0.5
1500 -0.5 +0.5
1600 -0.5 +0.5
1700 -0.5 +0.5
1800 -0.5 +0.5
1900 -0.5 +0.5
2000 -0.5 +0.5
2100 -0.5 +0.5
2200 -0.5 +0.5
2300 -0.5 +0.5
2400 -0.5 +0.5
2500 -0.5 +0.5
2600 -0.5 +0.5
2700 -0.5 +0.5
2800 -0.5 +0.5
2900 -0.5 +0.5
3000 -0.5 +0.5
3100 -2.0 +2.0
3200 -2.0 +2.0
