R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-143
• Frequency Range 14.7 GHz to 27 GHz for R3182
Preamplifier
Test Data
(MHz)
Specification Result
Min. (dB)
Measured
Value (dB)
Max. (dB) Pass/Fail
OFF 14800 -3.0 +3.0
15000 -3.0 +3.0
15200 -3.0 +3.0
15400 -3.0 +3.0
15600 -3.0 +3.0
15800 -3.0 +3.0
16000 -3.0 +3.0
16200 -3.0 +3.0
16400 -3.0 +3.0
16600 -3.0 +3.0
16800 -3.0 +3.0
17000 -3.0 +3.0
17200 -3.0 +3.0
17400 -3.0 +3.0
17600 -3.0 +3.0
17800 -3.0 +3.0
18000 -3.0 +3.0
18200 -3.0 +3.0
18400 -3.0 +3.0
18600 -3.0 +3.0
18800 -3.0 +3.0
19000 -3.0 +3.0
19200 -3.0 +3.0
19400 -3.0 +3.0
19600 -3.0 +3.0
19800 -3.0 +3.0
20000 -3.0 +3.0
20200 -3.0 +3.0
20400 -3.0 +3.0
20600 -3.0 +3.0
20800 -3.0 +3.0
21000 -3.0 +3.0
21200 -3.0 +3.0
21400 -3.0 +3.0
