ADVANTEST R3162

R3132 Series Spectrum Analyzer Operation Manual
5.5 Performance Verification Record Sheet
5-158
• Offset Error (External Mixer Mode)
• Linearity Error (External Mixer Mode)
Range
Specification Result
Min. (Hz) Measured Value (Hz) Max. (Hz) Pass/Fail
1 kHz/ 0 2.4 k
2.5 kHz/ 0 3 k
5 kHz/ 0 4 k
10 kHz/ 0 6 k
25 kHz/ 0 18 k
50 kHz/ 0 28 k
100 kHz/ 0 48 k
250 kHz/ 0 108 k
500 kHz/ 0 328 k
1 MHz/ 0 528 k
2.5 MHz/ 0 1.128 M
5 MHz/ 0 2.128 M
10 MHz/ 0 4.128 M
25 MHz/ 0 10.128 M
50 MHz/ 0 20.128 M
Range
Specification Result
Min. (Hz) Measured Value (Hz) Max. (Hz) Pass/Fail
1 kHz/ 7.8 k 8.2 k
2.5 kHz/ 19.5 k 20.5 k
5 kHz/ 39 k 41 k
10 kHz/ 78 k 82 k
25 kHz/ 195 k 205 k
50 kHz/ 390 k 410 k
100 kHz/ 780 k 820 k
250 kHz/ 1.95 M 2.05 M
500 kHz/ 3.9 M 4.1 M
1 MHz/ 7.8 M 8.2 M
2.5 MHz/ 19.5 M 20.5 M
5 MHz/ 39 M 41 M
10 MHz/ 78 M 82 M
25 MHz/ 195 M 205 M
50 MHz/ 390 M 410 M
