Figure 3. Parts of the 35mm bulk load camera module.
— Feed magazine. — Take-up magazine.
—Film core. — Film spool. — Light seal rollers.
— Film cassette recess. — End of film sensor switch. — Film guide.
— Pressure plate. — Drive sprocket. — Film guide roller. — Light trap.
