152 Agilent 7100 Capillary Electrophoresis System User Manual
5 Using the Agilent 7100 Capillary Electrophoresis System
Capillary Electrochromatography, CEC
9 Close and restart ChemStation to fully apply the changes.
10 The activated CE+p mode is displayed in the top line of the CE diagram and
a new icon for an external pressure reservoir will appear, see Figure 46.
Figure 46 CE diagram with CEC mode activated
Damage or contamination of pressure valves.
Make sure tube "8" is connected properly before you apply high pressure to any lift.
High pressure may flush liquid into the pressure valves and lead to permanent
damage.
• Connect tube "8" prior to using high pressure.
