Vials and Bottles 6
Installation, Operation, and Maintenance 119
Part 2, Operation
If you do not use the optional 100-vial tray
You can place up to eight vials, a solvent A, a solvent B, and a waste bottle in
the 8-sample injector turret. If you use the 1-sample transfer turret, you can
only load 1 sample vial but the solvent and waste bottle capacity increases to
10. The transfer turret is generally used only with the tray. See Figure 53.
Table 1 7 Transfer turret labels
Position Label Bottle/Vial
1 SAMPLE Sample vial transfer position
2 WB Waste bottle B
3 WB Waste bottle B
4 WA Waste bottle A
5 WA Waste bottle A
6 B3 Solvent bottle B3
7 B2 Solvent bottle B2
8 B Solvent bottle B
9 A3 Solvent bottle A3
10 A2 Solvent bottle A2
11 A Solvent bottle A
