Replacement Parts 12
Installation, Operation, and Maintenance 191
Part 3, Maintenance and Troubleshooting
G2916A — 7683 ALS Tray for 5890 Series II GCs
Table 34 and Figure 79 list and show the replacement parts for the 7683B ALS
tray for 5890 Series II GCs.
Table 3 4 G2916A tray replacement parts
Item Description Part no. Qty/Assy
1 Tray module assembly (new)
Tray module assembly (exchange)
G2916-60965
G2916-69965
2 Quadrant, 4/pkg 18596-40015 1
3 Tray screw kit G2916-80510 1
4 Tray standoff G29116-25040 1
NS Main tray cable G2614-60610 1
Figure 79 G2916A tray replacement parts
1
2
3
4
