26 Installation, Operation, and Maintenance
Part 1, Installation
2 Installation
The Installation Process
The procedures for installing all or part of the 7683B ALS system depend on
the GC on which you are installing it and any existing hardware that you may
want to incorporate.
To install the ALS system:
1 Find the process table for the GC you are starting with.
2 Carry out the steps and procedures specified in the table.
3 Configure the GC and data system, if any, to use the new ALS hardware
(page 65).
4 Check the firmware and, if necessary, update it (page 66).
5 If using an injector with a cool on-column inlet, adapt the injector and inlet
as described in “Adapting For Cool On-Column Injection” on page 139.
6 Make a test run (page 66).
5890A, fully upgraded to Series II, and 5890 Series II GCs
Table 4 5890A, fully upgraded to Series II, and 5890 Series II GCs
Action Procedure
Remove the injector, if present.
Remove the tray, tray bracket and its supports, if present.
Remove the controller, if present.
Remove the injector mounting brackets, if present.
Install the G2916-61000 injector bracket and mounting posts. 1 on page 29
Install the G2916A tray, if desired. 2 on page 35
Install 1 or 2 7683A or 7683B injectors. 3 on page 42
Install the G2912A ALS controller. 8 on page 55
Connect all cables. 4 on page 46
Install the G2911AA software on the PC. 5 on page 50
Configure your GC and Data System. 11 on page 65
