Agilent Technologies agilent 7683B - 6890 A Gc; 6890 Plus GC

Installation 2
Installation, Operation, and Maintenance 27
Part 1, Installation
6890A GC
6890 Plus GC
Table 5 6890A GC
Action Procedure
Remove the injector, if present.
Remove the tray and its brackets, if present.
Remove the controller, if present.
Replace the inlet carrier cover. 9 on page 60
Install the G2614A tray
OR Install the G2916A tray with G2917A (G2917-64000) upgrade kit.
6 on page 51
2 on page 35
Install 1 or 2 injectors. 3 on page 42
Optional. Install the G2615A Bar Code Reader. 7 on page 53
Install the G2912A ALS controller. 8 on page 55
Connect all cables. 4 on page 46
Update your Firmware. 12 on page 66
Configure your GC and Data System. 11 on page 65
Table 6 6890 Plus GC
Action Procedure
Remove the injector, if present. Save the 7683A injector since it can be
used with the 7683B ALS system.
Remove the 18596 A, B, or C tray and bracket if present.
Install a G2612A ALS controller board in the GC, if not present. 10 on page 61
Install the G2614A tray
OR Install the G2916A tray with G2917A (G2917-64000) upgrade kit.
6 on page 51
2 on page 35
Install 1 or 2 7683A or 7683B injectors. 3 on page 42
Optional. Install the G2615A Bar Code Reader. 7 on page 53
