Agilent Technologies agilent 7683B User Manual

Cables and Connectors A
Installation, Operation, and Maintenance 199
G2912-60507 — Remote Start/Stop Cable for 5890 Series II GCs
Figure 82 G2912-60507 cable
Table 4 2 G2912-60507 cable
Pin # Connector 1 Connector 2 Description
110
212
3 4 Not defined
43Start out
5 9 Not defined
68Start out
72Ready
85
9 7 Configuration
10 11 Configuration
11 1 Start in
12 6 GND
13
14
15
G2912-60507
CHINA
xx-xx-xxxx
1
515
11
12
21
11
Connector 1, Female
Connector 2, Male
