Agilent Technologies agilent 7683B User Manual

198 Installation, Operation, and Maintenance
A Cables and Connectors
Table 4 0 RS-232 connector
9600 baud
No hardware handshake
Pin # Description
1 DCD-1, Data carrier detect
2RX-1, Receive data
3 TX-1, Transmit data
4 DRT-1, Data terminal ready
5 Signal ground
6 DSR-1, Data set ready
7 RTS-1, Request to send
8 CTS-1, Clear to send
9 RI-1, Ring indicator
Table 4 1 5890 connector
Pin # Description
1Start out
2Ready in
3 Start request in
4Ready in
5 Not used
6Start out
7 Jumpered to 11
8 Not used
9 Start request in
10 Not used
11 Jumpered to 7
12-15 Not used
