Agilent Technologies agilent 7683B User Manual

Cables and Connectors A
Installation, Operation, and Maintenance 197
G2612A — ALS Controller
Figure 81 G2912A ALS controller
Table 3 9 6890 Remote connector
Pin # Description
1 External ground
2 Not used
3 Start out, Low true
4-9 Not used
USE ONLY WITH 250V
FUSES/EMPLOYER
UNIQUEMENT AVEC
DES FUSIBLES DE 250V
110-120 V
220-240 V
Agilent Technologies
(Shanghai) Co., Ltd.
100-120/220-240VAC
50-60Hz
180VA MAX
5890 REMOTE
AC LINE
RS-232Front Injector Back Injector Tray
6890 REMOTE
CUS
220970
Run controls
Front
injector
Back
injector
Tray 6890 RS-232 5890 Power
module
Start
Stop
ALS Controller
ALS Controller
CN00000XXX
G2912A
Serial #
Remote Remote
