Chapter 5 Laser Processing by External Communication Control (RS-485 CONTROL)
Introduction Part Operating Part Maintenance Part Appendixes
Installation and
Preparation Part
Set Value/Monitor Value Table
⇒
The items marked * are monitor values. These values can be read out but can-
not be set.
⇒
The value in ( ) indicates the unit.
⇒
The unit of time setting depends on the setting of "RESOL" on the SCHEDULE
screen. When setting to 0.05 ms, set the values in increment of 5.
84 Schedule Settings for FIX, FLEX and CW
Data No.
Item Data Range
01
[FORM] on the [SCHEDULE] screen
Selection of waveform setting method
0: FIX 1: FLEX 2: CW
0 – 2
02
Turning ON/OFF the graph display on the
[SCHEDULE] screen
0: OFF 1: ON
Fixed to 1
03
[PEAK POWER] on the [SCHEDULE] screen
Laser output peak value
00000 – 00120 (×1W)
04
[REPEAT] on the [SCHEDULE] screen
Pulse repetition rate
FIX : 00001 – 05000
FLEX : 00001 – 05000
CW : 00001 – 99999
05
[SHOT] on the [SCHEDULE] screen
Number of consecutive shots
0001 – 9999
06
[HIGH] on the [MONITOR] screen
Energy monitor upper limit setting
FIX/FLEX : 000000 – 099999
(×0.1J/×0.01J)
CW : 000000 – 000999 (×1%)
07
[LOW] on the [MONITOR] screen
Energy monitor lower limit setting
FIX/FLEX : 000000 – 099999
(×0.1J/×0.01J)
CW : 000000 – 000999 (×1%)
08
Turning ON/OFF the graph display on the [MON-
ITOR] screen
0: OFF 1: ON
Fixed to 1
09 Unused Fixed to 100
85 Schedule Settings for FIX
Data No.
Item Data Range
01
[
SLOPE] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
02
[FLASH 1] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
03
[FLASH 2] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
04
[FLASH 3] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
05
[
SLOPE] TIME on the [SCHEDULE] screen
0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
06 Unused Fixed to 0000
07 [FLASH 1] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
