162
ML-5120A
4. Commands
Data No. Item Data Range
08 [FLASH 2] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
09 [FLASH 3] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
10 Unused Fixed to 0000
11*
[REFERENCE VALUE] on the [SCHEDULE] screen
Approximate laser output energy of the set waveform
000000 – 999999 (×0.01J)
12
[COOL 1] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
13
[COOL 2] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
86 Schedule Settings for FLEX ― TIME 01 to 10
Data No. Item Data Range
01
[POINT 01] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
02
[POINT 02] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
03
[POINT 03] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
04
[POINT 04] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
05
[POINT 05] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
06
[POINT 06] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
07
[POINT 07] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
08
[POINT 08] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
09
[POINT 09] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
10
[POINT 10] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
87 Schedule Settings for FLEX ― TIME 11 to 20
Data No. Item Data Range
01
[POINT 11] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
02
[POINT 12] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
03
[POINT 13] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
04
[POINT 14] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
05
[POINT 15] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
