4. Product Composition
4. Product Composition
Packaging
The main unit and accessories are packed together. The dimensions and mass are
as follows.
Dimensions Mass (including packaged products)
Approx. 1100 (H) × 600 (W) × 1155 (D) mm Approx. 100 kg
Checking the Packaged Products
Make sure that all the packaged products are included.
⇒
The model numbers of accessories are subject to change without notice. De-
pending on the part to be changed, the mounting screw shape may change and a
necessary tool may be di󰀨erent. For the latest parts information, contact a near-
est sales o󰀩ce.
Product name Model No. Q’ty
Direcr Diode Laser ML-5120A 1
Adjuster pressure plate KC-1275C-3 4
Protective glasses YL-717 Fiber Laser 1
Operation manual AS1183540(OM1183538,OM1183539) 1
Power harness (6 m) AS1178984 1
CE label P-1215 1
Connector
Plug
HDCB-37P(05) 1
116-12A10-5F10.5 2
Case HDC-CTH(10) 1
Main Unit, Optical Fiber, and Output Unit
This product is used in combination with the optical ber and output unit as shown
below.
Main unit x 1 +
Optical ber x
Number of deliveries
+
Output unit x
Number of deliveries
