ML-5120A
Chapter 5 Laser Processing by External Communication Control (RS-485 CONTROL)
Introduction Part Operating Part Maintenance Part Appendixes
Installation and Preparation Part
Stopping a Laser Light Output
The command (code: $9) to stop a laser light output is explained below.
CH1/CH0 Equipment No. (CH1 = tens digit, CH0 = units digit)
ACK or NAK
The Laser accepts the command only when in external communication con-
trol (RS-485 CONTROL) mode. It returns a [NAK] when in any other control
method.
Stopping an Error Signal Output
The command (code: C0) to stop an error signal output is explained below.
CH1/CH0 Equipment No. (CH1 = tens digit, CH0 = units digit)
ACK or NAK
The Laser accepts the command only when in external communication con-
trol (RS-485 CONTROL) mode. It returns a [NAK] when in any other control
method.
Resetting the Total Number of Outputs
The command (code: C1) to reset the total number of outputs (SHOT COUNT) is
explained below.
