196
ML-5120A
Dimensional Outline Drawings
Dimensional Outline Drawings
⇒
In the drawing below, the optional cooler unit is mounted.
Unit: mm
FIBER.OUT 1
FIBER.OUT 2
Front view
Rear view
Top view
Right side view
Left side view
(265)
400
971
696
900
Cooler unit
(option)
