4. Commands
163
ML-5120A
Chapter 5 Laser Processing by External Communication Control (RS-485 CONTROL)
Introduction Part Operating Part Maintenance Part Appendixes
Installation and
Preparation Part
Data No.
Item Data Range
06
[POINT 16] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
07
[POINT 17] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
08
[POINT 18] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
09
[POINT 19] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
10
[POINT 20] TIME on the [SCHEDULE] screen 0000 – 5000 (×0.1ms)
0000 – 9995 (×0.01ms)
88 Schedule Settings for FLEX ― POWER 01 to 10
Data No.
Item Data Range
01 [POINT 01] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
02 [POINT 02] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
03 [POINT 03] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
04 [POINT 04] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
05 [POINT 05] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
06 [POINT 06] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
07 [POINT 07] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
08 [POINT 08] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
09 [POINT 09] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
10 [POINT 10] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
89 Schedule Settings for FLEX ― POWER 11 to 20
Data No.
Item Data Range
01 [POINT 11] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
02 [POINT 12] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
03 [POINT 13] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
04
[POINT 14] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
05 [POINT 15] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
06 [POINT 16] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
07 [POINT 17] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
08 [POINT 18] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
09 [POINT 19] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
10 [POINT 20] POWER on the [SCHEDULE] screen 0000 – 2000 (×0.1%)
66 Schedule Settings for CW ― TIME 01 to 10
Data No.
Item Data Range
01 [POINT 01] TIME on the [SCHEDULE] screen 0000 – 9999 (×1s/×0.1s/×0.01s/×0.001s)
