1. Error Display and How to Take a Measure
185
ML-5120A
Chapter 2 Inspection and Measure To Be Taken at Occurrence of an Error
Introduction Part Operating Part Maintenance Part Appendixes
Installation and
Preparation Part
Chapter 2
●
Inspection and Measure To Be
Taken at Occurrence of an Error
1. Error Display and How to Take a Measure
When an error occurs in the laser, the contents of the error are displayed on
the laser controller screen as shown below. In the following, how to take a
measure is explained in the order of Error No. At occurrence of an error, read
this chapter carefully and perform inspection of the laser and take a proper
measure.
* If you have any unclear point, contact the distributor or us for information.
⇒
When there is any related page in this Operation Manual, the reference page is
shown.
<Note>
If the safety interlock is activated, a safety circuit will work to stop the safety
shutter forcibly. For this reason, “SAFETY SHUTTER OPEN/CLOSE TROUBLE”
may be displayed other than the relevant error/fault message.
LD "-": State of LD doesn’t change even if an error/fault occurs.
LD "OFF": LD is turned o automatically if an error/fault occurs.
Alarm output "-": Error/Fault signal is not output if an error/fault occurs.
Alarm output "ON": Error/Fault signal is output if an error/fault occurs.
Maintenance Part
Error No.
Contents of the error
(Troubles are displayed up to
ten occurrences.)
To Next Page
