Amada ML-5120A EU User Manual

168
ML-5120A
4. Commands
Pulse width Measurement interval
0.50 to 0.90 ms 0.01 ms
0.95 to 1.80 ms 0.02 ms
1.85 to 4.50 ms 0.05 ms
4.55 to 9.00 ms 0.1 ms
9.05 to 18.00 ms 0.2 ms
18.05 to 45.00 ms 0.5 ms
45.05 to 90.00 ms 1.0 ms
90.05 to 180.00 ms 2.0 ms
180.05 to 450.00 ms 5.0 ms
450.05 to 900.00 ms 10.0 ms
⇒
Since the number of data to be sent each time is limited to 5, it is necessary to
change the classication No. according to the "number of waveform data of the
laser power monitor" sent by "R00 nn 04" to perform repeated reading.
51 LD Output Total Time
Data No. Item Data Range
01* [FLASH WORK TIME] on the [STATUS] screen 0000000 – 9999999 (×0.1H)
40 Backup Memory Settings
Data No. Item Data Range
01* [NETWORK #] on the [CONFIG] screen 00 – 15
02* [IP ADDRESS] on the [CONFIG] screen 000000000000 – 999999999999
03* [SUBNET MASK] on the [CONFIG] screen 000000000000 – 999999999999
04* [DEFAULT GATEWAY] on the [CONFIG] screen 000000000000 – 999999999999
05* Unused Fixed to 00
06* Unused Fixed to 000
07*
[POWER FEEDBACK MODE] on the maintenance
screen
LD output mode
0: Power feedback ON 1: Power feedback OFF
0 – 1
08* Unused Fixed to 00000000
09* Unused Fixed to 00000000
10* Unused Fixed to 00000000
11* Unused Fixed to 00000000
12* Unused Fixed to 00000000
13* Unused Fixed to 00000000
