4. Product Composition
RS-232C/RS-485 Conversion Adapter
This conversion adapter is used to control equipment by external communication.
Output signals (RS-232C) of the personal computer are converted into RS-485 sig-
nals and then output to the main unit.
RS-485 cable
Personal computer, etc.
RS-485 connector of the main unit
RS-232C/RS-485
conversion adapter
RS-232C cable
