2. Connecting the Optical Fiber
51
ML-5120A
Chapter 2 Connections and Preparations of Each Section
Introduction Part
Installation and
Preparation Part
Operating Part Maintenance Part Appendixes
(3) Turn the outer-side nut of the plug in the direction of the arrow to x the optical
ber.
⇒
Tighten the nut by hand without using a tool.
⇒
The connector section cannot be bent. Take care not to give excessive force to
this section.
⇒
Keep the recover cap in a clean place in custody. If a dirty cap is mounted again,
this will cause seizure.
Optical ber
Output unit
Approx. 40mm
Connector section
