2. Checking the Equipment Status
69
ML-5120A
Chapter 2 Various Settings
Introduction Part
Installation and
Preparation Part
Operating Part Maintenance Part Appendixes
EXT. I/O (2)
(AHC external I/O
(option))
How to see the displayed items
: Settable item
INPUT
Displays the current status of external inputs.
OUTPUT
Displays the current status of external outputs.
EXT.I/O (1)
Moves to the EXT. I/O (1) screen.
EXT.I/O (2)
Moves to the EXT. I/O (2) screen.
SIM.
Sets the external output simulation mode to ON/OFF. This can be turned ON
only at PANEL CONTROL.
X
Returns to the STATUS screen. When the SIM. is ON, this cannot be changed.
To Next Page
