86
ML-5120A
3. Changing the Equipment Settings
OFFSET
Sets the deviation of the measured temperature in the range of -50.0 to 50.0.
The initial value is 0.0.
Moves in parallel with the full measurement range. Also, linearly corresponds
to the temperature indicated value.
CURT.TEMP.
The current measured temperature is displayed. When it is outside the measur-
ing range, “----” is displayed.
X
Returns to the CONFIG screen.
PEAK-POWER SYNCHRONIZE SETTING
How to see the displayed items
: Settable item
SCHEDULE No.
Up to ve sets of schedules to synchronize can be set in No.1 to No.5.
In an example of the screen above, the
laser output peak values of SCHED-
ULEs #0 and #10 are synchronized. When the laser output peak value of #0
is changed, that of #10 is also changed into the same value. The laser output
peak value cannot be changed if the setting error will occur in the synchronous
schedule.
Also, [LINKED: #] is displayed at the upper right portion of the SCHEDULE
screen of the set SCHEDULE number to recognize the synchronous target.
X
Returns to the CONFIG screen.
