Amsco 110LS - Table 6-2. Interlock Codes and Functionality

6-56
387366-389 Operator Manual Sterilizer Operation
Graphic of Interlock
Type Selected
Interlock
Button
Interlock Type
Selected
Table 6-2. Interlock Codes and Functionality
Code
Non-Sterile
Door
Sterile
Door
Comments Concept Image
0
AB
• No Interlocks.
• Either door can be used to load/unload.
• Both doors can be opened at same time.
• At end of cycle, both doors automatically unseal.
1
AB
• Door A is designated as Non-Sterile end.
• Sterilizer must be loaded from Door A.
• Either door can be used to unload.
• At end of cycle operator must manually unseal
unload door by pressing UNSEAL DOOR button
on touch screen.*
,†
2
Default
AB
• Door A is designated as Non-Sterile end.
• Either door can be used to load sterilizer.
• Sterilizer must be unloaded from Door B.
• At end of cycle Door B is automatically unsealed.*
,†
3
BA
• Door B is designated as Non-Sterile.
• Sterilizer must be loaded from Door B.
• Either door can be used to unload.
• At end of cycle operator must manually unseal
unload door by pressing UNSEAL DOOR button
on touch screen.
‡
4
BA
• Door B is designated as Non-Sterile.
• Either door can be used to load sterilizer.
• Sterilizer must be unloaded from Door A.
• At end of cycle Door A automatically unseals.
‡
5**
A
Locked
Out
• Door A is designated as Non-Sterile end.
• NOE Door is locked out.
• Sterilizer must be loaded/unloaded from Door A.
• At end of cycle Door A automatically unseals.
Load/Unload
A B
Load/Unload
Load/Unload
Load
A B
A B
2 Options
Load
A B
Load/Unload
Unload
L o a d / U n l o a d
Load
A B
A B
2 Options
Load
A B
Load/Unload
Locked
Out
Load/Unload
A B
