Amsco 110LS - Environmental Conditions; Utility Requirements for Units Using Facility Steam

2-3
Installation Verification Operator Manual 387366-389
2.2.5 Environmental
Conditions
Temperature: 10° to 32°C (50° to 90°F)
Humidity: 10 to 90% noncondensing
Pollution Degree: 2
Altitude Range: 0 - 1829 m (0 - 6,000 ft)
Installation Category (Overvoltage Category): II
A-Weighted Sound Power Level: 85 dBA (maximum)
2.2.6 Utility Requirements
For Units Using Facility Steam
• Electric:
•Steam:
Pressure: 50 to 80 psig (344.7 to 551.6 Kpa)
Consumption:
• 16 x 16 x 26" (406 x 406 x 660 mm) 83 lb/hr (38 kg/hr ) peak
• 20 x 20 x 38" (508 x 508 x 965 mm) 116 lb/hr (53 kg/hr ) peak
• Cold Water:
Pressure: 206.8 to 344.7 Kpa (30 to 50 psig)
Temperature: 70°F (21
o
C, maximum)
Consumption: Peak 6 gpm
Control Box Power (Units using Facility Steam)
Voltage
(Vac)
# Phases Frequency Nominal
Current
Circuit
Protection*
120 1 50/60 Hz 2.0 A 20 A
Vacuum Pump Power (Units using Facility Steam)
Voltage
(Vac)
# Phases Frequency Nominal
Current
Circuit
Protection*
208/240
3 50/60 Hz
6.0 A
20 A
380/415 4.0 A
440/480 3.0 A
575/600 3.0 A
* Circuit should be protected from exceeding the amp value shown, which is
the maximum current rating
.
