2-1
Installation Verification Operator Manual 387366-389
INSTALLATION VERIFICATION
2.1 Installation
Checklist
An equipment drawing showing all utility and space requirements
was supplied with the sterilizer. Clearance space shown on the
drawing is necessary for ease of installation and to help ensure
proper operation and maintenance of equipment. Uncrating and
Installation Instructions were also furnished with the sterilizer. If any
of these documents are missing or misplaced, contact STERIS
giving the serial and model numbers of the equipment. Replacement
copies will be sent out promptly.
After installing this unit according to the instructions provided,
complete the following checklist to help ensure installation is
complete and correct. Or, if desired, call STERIS to schedule a
technician to test the installation and demonstrate proper equipment
operation.
2.1.1 Service Clearance Clearance as specified on the equipment drawing must be available.
2.1.2 Plumbing Services Feed Water:
• All supply line shutoffs must be provided with lockout
capability.
• Backflow prevention is not provided by STERIS.
• Water Pressure–supplied must be within specifications as
shown on the equipment drawing. If pressure is too high, a
regulator must be installed. If water pressure is too low,
equipment performance is affected.
• Water Quality–supplied must be within specifications.
Improper water quality adversely affects equipment
operation. Damage to the equipment due to improper water
quality is not covered under warranty.
Steam Supply:
• Shutoffs (with provisions for lockout and tagout) located
nearby.
• Supply piping adequately sized.
• Supply pressure measured (specification is 3.5 to 5.2 bar
[50 to 80 psig], dynamic).
• Drain piping must be sloped properly, and sized to handle
the maximum waste flow from the sterilizer.
CAUTION – POSSIBLE
EQUIPMENT DAMAGE
HAZARD: Insufficient service
clearance will make repairs
more difficult and time-
consuming.
