A-1
Appendix A Operator Manual 387366-389
APPENDIX A — SUPPLEMENTAL INFORMATION
PLC SPECIFICATIONS
PLC: MicroLogix
®
1400 Controller*
Catalog number: 1766-L32AWAA
Agency Certification: UL 508, C-UL under CSA C222.2 no. 142,
Class I, Div. 2, Groups A, B, C, D (UL 1604, C-UL under CSA C222.2
no. 213) and CE
Operating temperature: 0ºC to 55ºC (32ºF to 131ºF) ambient.
Storage temperature: -40º C to 85ºC (-40º F to 185ºF) ambient.
Operating humidity: 5% to 95% relative humidity (non-condensing)
Variables stored in flash memory for permanent storage.
Optional Memory module for program backup. 1766-MM1
RTD MODULE: 4 CHANNEL INPUT MODULE
Catalog number: 1762-IR4
Resolution: 0.1ºC (0.1ºF)
Repeatability: +/-0.2ºC (+/- 0.4ºF)
Accuracy: +/-0.9ºC (+/- 1.62ºF)
Maximum drift: +/-0.026ºC/ºC (+/- 0.026º F/ºF)
RELAY OUTPUT MODULE: AC OUTPUTS
16 AC Outputs, Catalog number: 1762-O16
DISPLAY: PANELVIEW PLUS
®
7 700*
Catalog number: 2711P-T7C22D9P-B
SCADA TABLE
The following table shows the PLC tag locations for the value
descriptions.
Value Description Tag Value
Purge Minutes F94:0
Purge Seconds F94:1
Pulse Vacuum F94:2
Pulse Charge F94:3
Pulses F94:4
Sterilize Temperature F94:5
Sterilize Hours F94:6
Sterilize Minutes F94:7
Sterilize Seconds F94:8
* MicroLogix 1400 Controller and Panel
View Plus are registered trademarks of
Rockwell Automation.
