Amsco 110LS - Interlocks

6-55
Sterilizer Operation Operator Manual 387366-389
6.20.2 Interlocks When sterilizer is equipped with double-doors, pressing INTERLOCK
from Change Values screen advances screen to allow operator to
select interlock type by means of numeric keypad. The interlock type
is displayed as numeric code is entered. Default interlock type is “2,”
which designates Door A as Non-Sterile end of unit and Door B as
Sterile end.
43 Automatic Duplicate
Print
Refer to SECTION 6.19.1, DUPLICATE PRINT.
Too Long In __________.
Applies to remaining line items, for example, Too Long In Air Brake, Too Long In Charge,
etc.
See SECTION 6.20.8, TOO LONG IN STEP.
44 Air Break To change time of a “Too Long In/To . . . “ type
parameter (listed in left column), perform following
steps:
a) Press time section of associated button, for
example, the Air Break button.
b) On resulting numeric keypad display, enter new
time value and press ENTER.
The new value is shown on screen.
44 Alarm
45 Charge
46 Evacuate
47 Exhaust
48 Jacket Charge*
49 Seal*
(Activate Seal)
50 Unseal*
(Deactivate Seal)
51 Pressurize
Generator
(1 to 120 min.)
These three Too Long To alarms pertain to Steam
Generator. To set parameters from Supervisor Mode:
a) Advance to Screen Page 2 of 6.
b) Select TOO LONG IN STEP button.
c) Set value for each “Too Long In...” parameter
Allowable parameter settings for three steam
generator alarms are provided beneath alarm.
52 Depressurize
Generator
(1 to 120 min.)
53 Close Generator
Drain
(1 to 60 secs.)
54 Open Generator
Drain
(1 to 60 secs.)
*
Exhaust, Jacket Charge, Seal and Unseal appear on the second “Set Too Long In...” screen.
Table 6-1. Parameters with Changeable Value (Cont’d)
Press applicable Parameter button and use keyboard display to enter new values.
Parameter Comments
