8-3
Routine Maintenance Operator Manual 387366-389
Figure 8-3. Take-Up Spool
6. Place paper between take-up spool; then push spool halves
together.
7. Tightly wind paper around spool two to three times; then place
spool back in original position (at top of printer compartment.
8. Close printer cover.
8.3 Clean Chamber
Drain Strainer
Important: The chamber drain strainer must be cleaned at least
once a day, preferably in the morning before running the first cycle.
1. Remove drain strainer from drain in chamber bottom.
2. Remove any obvious debris from strainer. If necessary, clear
screen in strainer using a brush, wire or similar tool.
3. Once strainer has been cleared of obvious debris, reverse
strainer under running water.
4. Replace strainer in chamber drain.
8.4 Flush Chamber
Drain
Flush chamber drain as follows whenever line becomes clogged:
1. Turn OFF steam supply valve. Wait until jacket pressure is zero.
Wait until chamber has cooled to room temperature.
2. Remove chamber drain strainer. Clean strainer using
procedures given above, if necessary.
3. Pour solution of 60 mL (~1/4 cup) of STERIS sonic detergent or
Liqui-Jet 2 Instrument Detergent and 500 mL (~1 pint) of hot
water into drain. Solution may puddle in bottom of chamber.
… OR…
4. Should these detergents be unavailable, use hot solution of 15 mL
(~1 tablespoon) of tri-sodium phosphate to 500 mL (~1 pint) of hot
water.
5. Open door and return strainer to drain.
Spool (Assembled) Spool (Disassembled)
WARNING – BURN HAZARD:
• Allow sterilizer to cool to room
temperature before performing
any cleaning or maintenance
procedures.
• Failure to shut off the steam
supply when cleaning or
replacing strainers can result
in serious injury.
WARNING – BURN HAZARD:
• Allow sterilizer to cool to room
temperature before performing
any cleaning or maintenance
procedures.
• Failure to shut off the steam
supply when cleaning or
replacing strainers can result
in serious injury.
