6-98
387366-389 Operator Manual Sterilizer Operation
The baud rate is 38,400, 8 bit, no parity, one stop bit, no hardware
control. Data output is once per second.
Data string, see figure, consists of following:
First column: "S" or '–' (Dash)
S = sterilize phase
– (Dash) = cycle not in sterilize phase
Second column: time of day
Third column: AM, PM or spaces for MIL time
Fourth column: Pressure or shown as negative for vacuum
Remaining columns show temperature in following order: Chamber,
Jacket, Waste, Load 1, Air Detector (Load 2), Filter, Reference.
6.21 21 CFR Part
11 with Audit trails
and Electronic
Signatures
INTRODUCTION AND SETUP
The 21 CFR Part 11 feature will allow for record retention and
traceability on LS Series Sterilizer. This is accomplished by using User
Management system, Audit Trails and option Electronic Signatures on
Sterilizer control.
The 21 CFR Part 11 feature can be selected in configuration mode of
Serial Output Data String As Seen In HyperTerminal Software
