5-4
387366-389 Operator Manual Control Interface
Press PRINT CYCLE VALUES button to print all cycle values. The
following is a print example of all cycles values.
NOTE: STRL, CTRL and Fo only appear if load probes are selected.
================================
= CYCLE VALUES PRINTOUT =
================================
8/2/2016 11:27:34 AM
LOGIN NAME: STERIS
STERILIZER: VAC01
1.PREVAC
PURGE TIME= 2:00
PULSE VAC = 10.0 inHg
PULSE CHG = 15.0 PSIG
PULSES = 4
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
UNDERTEMP = RESUME
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
EXHAUST = FAST
DRY CONT = LIMIT
SLOW EXH. = 1.6 PSI/MIN
SLOW EXH. = 4.2 PSIG
SLOW EXH. = 0.6 PSI/MIN
SLOW EXH. = 5.0 inHg
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
VAPOR REM = 10 MIN
-------------------------------
2.GRAVITY
PURGE TIME= 2:00
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
DRY CONT = LIMIT
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
-------------------------------
3. LIQUID
PURGE TIME= 2:00
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
UNDERTEMP = RESUME
PRINT INT = 2 MIN
SLOW EXH. = 1.6 PSI/MIN
SLOW EXH. = 4.2 PSIG
SLOW EXH. = 0.6 PSI/MIN
SLOW EXH. = 5.0 inHg
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
VAPOR REM = 10 MIN
-------------------------------
4.LAB WASTE
PURGE TIME= 2:00
PUL VAC 1 = 20.0 inHg
PUL HLD 1 = 10 SEC
PUL CHG 1 = 15.0 PSIG
PUL VAC 2 = 10.0 inHg
PUL HLD 2 = 10 SEC
PUL CHG 2 = 15.0 PSIG
PUL VAC 3 = 5.0 inHg
PUL HLD 3 = 10 SEC
PUL CHG 3 = 10.0 PSIG
PULSES = 3
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
7.PREVAC
PURGE TIME= 2:00
PULSE VAC = 10.0 inHg
PULSE CHG = 15.0 PSIG
PULSES = 4
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
UNDERTEMP = RESUME
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
EXHAUST = FAST
DRY CONT = LIMIT
SLOW EXH. = 1.6 PSI/MIN
SLOW EXH. = 4.2 PSIG
SLOW EXH. = 0.6 PSI/MIN
SLOW EXH. = 5.0 inHg
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
VAPOR REM = 10 MIN
-------------------------------
8.PREVAC
PURGE TIME= 2:00
PULSE VAC = 10.0 inHg
PULSE CHG = 15.0 PSIG
PULSES = 4
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
UNDERTEMP = RESUME
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
EXHAUST = FAST
DRY CONT = LIMIT
SLOW EXH. = 1.6 PSI/MIN
SLOW EXH. = 4.2 PSIG
SLOW EXH. = 0.6 PSI/MIN
SLOW EXH. = 5.0 inHg
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
VAPOR REM = 10 MIN
-------------------------------
9.PREVAC
PURGE TIME= 2:00
PULSE VAC = 10.0 inHg
PULSE CHG = 15.0 PSIG
PULSES = 4
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
UNDERTEMP = RESUME
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
EXHAUST = FAST
DRY CONT = LIMIT
SLOW EXH. = 1.6 PSI/MIN
SLOW EXH. = 4.2 PSIG
SLOW EXH. = 0.6 PSI/MIN
SLOW EXH. = 5.0 inHg
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
VAPOR REM = 10 MIN
-------------------------------
10.PREVAC
PURGE TIME= 2:00
PULSE VAC = 10.0 inHg
PULSE CHG = 15.0 PSIG
PULSES = 4
STER TEMP = 121.0 °C
13.GRAVITY
PURGE TIME= 2:00
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
DRY CONT = LIMIT
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
-------------------------------
14.GRAVITY
PURGE TIME= 2:00
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
DRY CONT = LIMIT
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
-------------------------------
15.GRAVITY
PURGE TIME= 2:00
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
DRY CONT = LIMIT
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
-------------------------------
16.GRAVITY
PURGE TIME= 2:00
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
PRINT INT = 2 MIN
VAC DRY = 10.0 inHg
DRY TIME = 0:05:00
DRY CONT = LIMIT
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
-------------------------------
17. LIQUID
PURGE TIME= 2:00
STER TEMP = 121.0 °C
STER TIME = 0:30:00
OVERTEMP = 6.0 °C
OVERDRIVE = 1.5 °C
UNDERTEMP = 1.0 °C
UNDERTEMP = RESUME
PRINT INT = 2 MIN
SLOW EXH. = 1.6 PSI/MIN
SLOW EXH. = 4.2 PSIG
SLOW EXH. = 0.6 PSI/MIN
SLOW EXH. = 5.0 inHg
CHARGE = 1.0 PSI/MIN
EXHAUST = 10.0 PSI/MIN
EVACUATE = 10.0 PSI/MIN
VAPOR REM = 10 MIN
-------------------------------
18. LIQUID
PURGE TIME= 2:00
STER TEMP = 121.0 °C
NOTE: LAB WASTE cycle values (not shown) will look like a PREVAC cycle values printout.
Continued on Next Page ...
