5-7
Control Interface Operator Manual 387366-389
After the jacket drain cycle is complete, the following screen is shown:
Jacket steam is OFF. Press STANDARD MODE button to return to
standard mode (gravity and liquid cycles).
NOTE: A cycle cannot be run with door open. The cycle may be run
with the jacket still charging.
Press CYCLE button to select a cycle. Corresponding cycle values
appear on display for cycles 1 through 20 (cycles 13-20 are reserved
for isothermal cycles).
NOTE: If display shows CLOSE DOOR(S) message, close door(s).
The cycle does not start until doors are closed.
