UG-1828 Preliminary Technical Data
Rev. PrB | Page 162 of 277
relates to the selection of gain table. User should first select Rx gain table type at the bottom of this configuration page in TES.) The
second section displays the current gain control mode. If AGC is configured as shown in Figure 149 users are not allowed to enter the
other parameters in this section. If MGC is configured as shown in Figure 150, user should further configure other parameters. With
MGC Pin mode, user should configure the targeted Manual Gain Index as well as the step sizes. The third section displays the detection
mode user selected and it allows user to configure the signal detector related operating parameters, such as Peak Overload threshold and
Peak Underload Threshold (they apply to both APD and HB detectors), Gain Refresh Period, Max Gain Index, and Min Gain Index
when Peak Only mode is selected. Note some selections are greyed out either because they are not configurable due to current software
limitation or not applicable in the selected modes. TES provides sanity checks for the parameter user enters so when the value is out of
range, the user input is not allowed.
Figure 151. TES Configuration for Rx Interface Gain, Signal Detection Parameters and Manual Control Mode Parameters (when AGC is Configured)
