Analog Devices ADRV9002 User Manual

Preliminary Technical Data UG-1828
Rev. PrC | Page 289 of 338
7
TX_2_LO_LDO
2
VTX2LO_1P0
H3
Powered off, ch2 not required
8
CLK_PLL_SYNTH_LDO
1
N/A
N/A
Left on
9
CLK_PLL_VCO_LDO
1
VCLKVCO_1P0
H5
Left on
10
CLK_PLL_LP_SYNTH_LDO
1
N/A
N/A
Left on
11
CLK_PLL_LP_VCO_LDO
1
VCLKVCO_1P0
H5
Left on
12
LO1_PLL_SYNTH_LDO
2
N/A
N/A
Powered off, using external LO
13
LO1_PLL_VCO_LDO
2
VRFVCO1_1P0
B9
Powered off, using external LO
14
LO2_PLL_SYNTH_LDO
2
N/A
N/A
Powered off, LO2 not required
15
LO2_PLL_VCO_LDO
2
VRFVCO2_1P0
B6
Powered off, LO2 not required
16
AUX_PLL_SYNTH_LDO
1
N/A
N/A
Left on
17
AUX_PLL_VCO_LDO
1
VAUXVCO_1P0
H10
Left on
18
SRAM_LDO
1
VDIG_0P9
M8
Left on
The C# implementation of this configuration will be the following:
adi_adrv9001_PowerManagementSettings_t initialize_powerManagementSettings_35 = {
.ldoPowerSavingModes = { ADI_ADRV9001_LDO_POWER_SAVING_MODE_1,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_1, ADI_ADRV9001_LDO_POWER_SAVING_MODE_5,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_5, ADI_ADRV9001_LDO_POWER_SAVING_MODE_5,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_2, ADI_ADRV9001_LDO_POWER_SAVING_MODE_2,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_2, ADI_ADRV9001_LDO_POWER_SAVING_MODE_1,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_1, ADI_ADRV9001_LDO_POWER_SAVING_MODE_1,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_1, ADI_ADRV9001_LDO_POWER_SAVING_MODE_2,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_2, ADI_ADRV9001_LDO_POWER_SAVING_MODE_2,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_2, ADI_ADRV9001_LDO_POWER_SAVING_MODE_1,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_1, ADI_ADRV9001_LDO_POWER_SAVING_MODE_1 }
