4-47
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
Item Range Initial value
RX Meas.frequency Using Specification:IS-95A,TSB74 870.030MHz Note2
870.000+0.030N[MHz]
(Channel(N):1 to 799CH)
870.000+0.030(N-1023)[MHz]
(Channel(N):990 to 1023CH)
Using Specification:J-STD-008
1930.000+0.050N[MHz]
(Channel(N):0 to 1199CH)
Using Specification:ARIB-T53
860.000+0.0125N[MHz]
(Channel(N):1 to 799CH)
843.000+0.0125(N-800)[MHz]
(Channel(N):801 to 1039CH)
832.000+0.0125(N-1040)[MHz]
(Channel(N):1041 to 1149CH)
Using Specification:KOREA-PCS
1840.050+0.050N[MHz]
(Channel(N):1 to 600CH)
1805.050+0.050(N-600)[MHz]
(Channel(N):601 to 1300CH)
Level
Reference Level –60dBm to 42dBm (RF Input:Main) 30.0dBm Note3
–60dBm to 22dBm (RF Input:AUX)
Auto Set On,Off Off Note3
BS Output Level(Total) –133.0dBm to –18.0dBm (RF Output:Main,AWGN Off) –55.0dBm Note4
–133.0dBm to 2.0dBm (RF Output:AUX,AWGN Off)
–133.0dBm to –24.0dBm (RF Output:Main,AWGN On)
–133.0dBm to –4.0dBm (RF Output:Aux,AWGN On)
AWGN Level –20.0dB to 6.0dB –20.0dB Note5
(/1.23MHZ)
AWGN On,Off On,Off Off Note5
Access Parameter –8dB to 7dB 0dB Note6
NOM_PWR
Access Parameter –16dB to 15dB 0dB Note6
INIT_PWR
MS Power Lever(VMAC) 0 to 7 2 Note9
Siganl
Service Option SO1,SO2,SO3,SO9 SO2 Note7
Data Rate Full,1/2,1/4,1/8 Full Note8
Call Drop Threshold On,Off 50 Frames to 500 Frames Off,250 Frames Note11
Echo Delay 0 sec to 5 sec 1 sec Note12
