Section 5 Measurement Examples
5-26
5.2.10 Measuring access probe output power
Access probe output power is one-time access channel output power that consists of
the pre-ample and the message. Nominal power offset of access channel output
power, initial power offset, power increment in continuous probes, number of probes
in one-time access probe sequence, and number of probe sequences in one-time access
attempt are measured in this section.
Measurement procedure
The explanation in this section starts at the completion of the setting explained in 5.1.2
“Setting MT8801C and the CDMA mobile station”.
(1) Press the F6 (Main Func On Off) key to turn On the Main Func.
(2) Press the F1 (TX & RX Tester) key.
(3) Press the key of Next Menu to display the second page of main function keys
(F1 to F6).
(4) Press the F5 (Stop) key to release the Loopback status.
(5) Turn OFF the CDMA mobile station power.
(6) Set the following items on the Setup Common Parameter screen:
♦ Set Access Parameter NON_PWR at 0.
♦ Set Access Parameter INIT_PWR at 0 dBm.
(7) Press the key of Next Menu to display the first page of main function keys (F1
to F5).
(8) Press the F1 (TX Measure) key.
(9) Press the key of Next Menu to display the second page of function keys (F7
to F12).
(10) Press the F9 (Setup TX Parameter) key.
(11) Set the following items on the Setup TX Measure Parameter screen:
♦ Set Access Parameter PWR_STEP at 0 dB.
♦ Set Access Parameter NUM_STEP at 4.
♦ Set Access Parameter MAX_RSP_SEQ at 1.
♦ Set Measuring Period to be 2000 Frame.
♦ Set Measuring Number to be 15AP.
(12) Press the F6 (Main Func On Off) key to turn On the Main Func.
(13) Press the F1 (TX & RX Tester) key.
(14) Press the key of Next Menu to display the second page of main function keys
(F1 to F5).
(15) Press the F5 (Start) key.
(16) Turn ON the CDMA mobile station power.
(17) Wait until the Idle status of Call Proc. becomes the Idle (Regist) status.
(18) Press the F8 (Access Probe Measure) key.
