3.2 Setting GPIB Interface Conditions
3.2 Setting GPIB Interface Conditions
Set the GPIB interface on the Instrument Setup screen at the front panel.
Set the following items:
(1) Interface: Connect to Controller (Initial value: GPIB)
(2) GPIB: Address (Initial value: 01)
An example of the setting when the GPIB interface is set with the GPIB address03 is
given below.
Step Key operation Explanation
(Switching to the Instrument Setup screen)
1. [Main Func on off] F6 Sets the Main Func on to display the main menu.
2. Next Menu [ ] Sets the Instrument Setup mode.
[Instrument Setup] F2 Displays the Instrument Setup screen.
(Selecting the remote control interface)
3. Cursor [ ] [ ] Uses these cursor keys to select “Interface Connect to Controller.”
4. [Set] Opens the setup window.
5. Cursor [ ] [ ] Selects GPIB on the setting window.
6. [Set] Closes the setting window and determines the set value.
(Setting the GPIB address)
7. Cursor [ ] [ ] Use these cursor keys to select a GPIB address.
8. [Set] Opens the setup window.
9. [0] [3] [Set] Set the GPIB address to 03.
