3.2 Overview of Operation
3.2.2 Overview of operation
At power-on operation begins in “TX&RX Tester” (Transmitter and Receiver test)
status (Setup Common Parameter screen).
(1) Main menu selection
If measurement is to be started from another mode, or from other than a mea-
surement mode, first select one of the main menu items, as shown below.
TX&RX Tester (Transmitter and Receiver test)
Recall (Parameter file recall)
Save (Parameter file save)
File Operation (File retrieval/deletion/protect, FD initialization)
Change System (Measurement system change)
Instrument Set (MT8801C main-frame setting)
Change Color (Selection of screen color)
First press the [Main Func On/Off] F6 key to ON, then select the desired func-
tion by using main function keys F1 to F5 and the Next Menu key [ ].
(2) Selection of measurement items
Items are set by using cursor keys ([ ],[ ],[ ], [ ]), and other function
keys while observing the screen menu.
Press the [Set] key to open the input window.
(3) Item input
For selection items displayed:
Select the required value using the cursor keys and validate it by using the [Set]
or [Enter] key. The window closes.
For numeric values:
Input data using the numeric keys or change data using the rotary knob and
[Step] keys. Validate by pressing a unit key, [Enter] key, or [Set] key. The
window closes.
