4-25
4.3 CDMA Transmitter and Receiver Test --- TX and RX Tester Mode
4.3.2 Selecting and changing the measurement system: Change Sys-
tem screen
Change the measurement system according to the following steps.
For measurement after change, refer to the manual of the selected measurement sys-
tem.
Step Key operation Description
1. [Main Func on off] F6 Sets the Main Func on.
The Main Menu appears at the bottom of the screen.
Next Menu [ ] Displays the second page of the Main Menu.
2. [Change System] F1 Sets Change System mode.
The Change System screen and System menu appear.
This screen is used to select anyone of measuring systems and to upgrade the system
software.
Note:
Changing any measuring system in this screen initializes the corresponding
measurement parameters. Save the parameters before changing if necessary.
