Section 4 Operation
4-26
(1) Changing the built-in measuring system
This paragraph describes how to exchange the measuring system used when
more than one measuring systems are built in the MT8801C.
Step Key operation Description
1. Make sure that “Current System” shows the system currently selected and
that “Application Memory” contains a new measuring system to select.
2. Cursor [ ] [ ] Select one of the measuring system softwares in the “Application Memory”.
Displays one of the measuring system softwares in the “Application
Memory” in reverse display.
3. [Change System] F7 Sets Change System mode.
Cursor [<] [>] Select “Yes” and Press the [Set] to confirm the measuring system software.
(2) Loading measuring systems from an external floppy disk
This paragraph describes how to load measuring systems from an external
floppy disk.
(This function is effective only when the measuring software floppy disk is
used.)
Step Key operation Description
1. Set the floppy disk containing measuring system files in the floppy disk driver of the MT8801C.
2. [Floppy Disk Dir] F8 Displays measuring system files on the floppy disk. Here, confirm the
“Unused area” under “Application Memory”, and also the size of the
measuring systems on the floppy disk.
The measuring systems can be loaded when the value in “Unused area” is
greater than size of measuring systems to be loaded.
3. [Install system form FD] F10 Loads measuring system from the floppy disk to “Application Memory.”
4. Set Make sure that the measuring systems are displayed (saved) in “Application
Memory.”
To Next Page
